Input Voltage Range DC9V¡«16V
Starting Voltage DC12.8V
Input Current 3.2A
Max. Inrush Current 15A
Output Power 32W-38W
Output voltage AC85V¡À15V
Output Frequency 260Hz¡«280Hz
Efficiency: ¡Ý84%
Ignition pulse Typical peak Voltage 23kV Typ. 1s
Input Protections Under voltage protection at 6V¡À1V
Over voltage protection at 27.5V¡À1V
Input connection-reverse protection
Output Protections Short circuit protection between two outputs
Open circuit protection between two outputs
Size(Unit:mm) Length 84 Width 62 Height 12
¡¡ |
